KOSMEK Online ExhibitionFA・Robot・Welding Exhibition
High-Power Automation Pallet ClampThe pallet clamp enables simple and quick fixture setup with simultaneous locating and clamping function. Safety is ensured by powerful holding force, and the low-profile body allows for smooth loading/unloading.
Locating Pin Clamp for WeldingHigh-accuracy locating and powerful clamping of a workpiece possible with Locating Pin Clamp. Floating model and smaller diameter model for Φ8/Φ9mm are newly added to the lineup. Suitable for welding application, transfer and more.
Manual Robotic Hand ChangerNew release of "Manual Robotic Hand Changer SXR" best suitable for collaborative robot.
Safety Push Valve (Fall Prevention Valve)The valve to prevent a tool fall caused by a valve operating error. It limits the Robotic Hand Changer (model SWR) to release only at a designated position (tool stocker). Best suitable for preventing a tool fall caused by a valve operating error during robot teaching.
You can download application examples.
Auto Fixture Changeover for Deburring ProcessAutomatic fixture pallet changeover with High-Power Pneumatic Pallet Clamp enables to design applications for a variety of workpieces. After setting a pallet with a robot, the pallet clamp secures clamping and locating at once.
With locating repeatability 3μm, it enables high-quality machining, reduces errors, and prevents accidents and machine stops caused by locating failures.
Moment-Resistible Gripper for Pallet TransferPallet Gripper for pallet transfer simplifies fixture setup and saves space of pallet stocker by approaching from the side.
Unlike other standard transfer hands, Pallet Gripper withstands high moment and best suitable for pallet transfer.
High-Accuracy Locating + Manual Cart + RobotUsing Kosmek FA＆Industrial Robot Related Products, we can connect a robot to a manual cart or an AGV with "Mechanical Lock".
Pallet Clamp connects a transferred robot to a working station with a robot and a fixture with high accuracy.
NO NEED of re-positioning with a camera or others, saving time and costs for correcting devices.
Solution with Welding Clamp and Tool StockerHaving trouble with frequent application stops caused by loading and locating failure during automatic transfer of welding workpieces?
KOSMEK offers automation products for welding application, and high-performance Locating Pin Clamp will solve automation problems.
Also, High-Power Pull Stud Clamp saves space for tools by setting a tool stocker above the robot.
Compact Ball Lock Cylinder to Transfer a Fixture of Soldering ProcessBall Lock Cylinder securely transfers a workpiece, and prevents a workpiece drop with steel balls (ball locking). The lightweight and compact design enables to maximize payload of a transfer robot.
Coupler Keeps Pressure in a Disconnected StateAfter locking a workpiece on a fixture with a clamp by supplying air pressure via Leakless Coupler, it enables to maintain clamping force of the fixture (to lock the workpiece) even when the coupler is disconnected from the air source.
The pressure maintaining Leakless Coupler requires no additional air tubes or air supply during fixture transfer between applications.
Compact Pull Stud Clamp for Fixture/Pallet TransferPull Stud Clamp is used by installing a pull bolt to a transferred object (fixture, pallet, etc.) and a pull stud clamp to a robot.
The ultra-light and compact pull stud clamp as a robotic hand enables powerful holding and maximizes robot payload. With a self-locking function it prevents a pallet drop even when air pressure is cut off. Also recommended to use the clamp as a tool locking function of a tool stocker.
Internal-Chucking Clamp to Transfer a Workpiece with a GantryHole Clamp powerfully clamps a workpiece hole. Enables workpiece transfer as a space-saving and light hand. (Model SWE can be used as a clamp in a machine tool.)
FA Pneumatic Hole Clamp (model WKH) is recommended for use in a clean environment and when requiring less gripping force than model SWE.
Air Pilot Check Valve for SafetyUltra-compact and light air pilot check valve.
It maintains air pressure even when air supply is stopped due to blackout.
Suitable for fall prevention of workpiece during transfer with a robot.
It is highly reliable with built-in Soft Seal.
Ultra-Smooth Compliance ModuleThree Remarkable Features of Compliance Module:
・Directly Mounted to Robotic Hand Changer
Workholding with "No Interference" around a WorkpieceWorkholding example by using Hole Clamp, Expansion Locating Pin and Work Support.
There is no unrequired interference around or on the workpiece, allowing for automation of testing, assembly, machining and more.
Stops at Contact！Gently Support a WorkpieceWork Support gently touches a workpiece and powerfully holds its plunger (rod). Enables to support a thin workpiece and prevent a workpiece deformation during press-fit and assembly.
Clamps for Washing ApplicationThese high-power pneumatic clamps are exclusively designed for washing application.
Please consider our products in need of automation for washing application.
Robotic Tool Change: Internal Chucks and External Chucks“High-Performance and High-Accuracy Robotic Hand Changer (model SWR)” that changes robotic hands and tools has no backlash and prevents locating errors that lead to troubles of automation.
Introducing tools for transfer hand: a hole clamp by gripping inside a workpiece hole (model WKH) and a cylinder that holds a workpiece with steel balls (model WKA).
Large Expansion Locating Pin enables both automation and locating.High-accuracy locating pin with expansion and retraction of pin head.
The 1.1mm large-expansion model enables “easy setup” and “high-accuracy locating” of a workpiece during automated transfer, assembly and machining, for improving productivity and quality, and reducing defect ratio.
3μm High-Accuracy Locating PinExpansion locating pin with the highest locating repeatability: 3μm among KOSMEK expansion locating pins.
Best for finishing and high-accuracy machining.
(Lineup: Pneumatic double acting model, hydraulic single-acting model and hydraulic double-acting model)
High-Accuracy Setup of Fixture Pallet｜Accuracy Testing｜Simple, quick and high-accuracy fixture pallet change with Pallet Clamp
Both automatic and manual fixture changes possible, reducing a fixture setup time to the minimum.
Setup of Robot｜High-Accuracy Re-Setting｜High-Accuracy Robot Setup Example
Using locating clamps with 3μm locating repeatability enables to eliminate re-teaching and re-positioning with a camera when re-setting the robot.
Lifting Hole ClampThree functions in one cylinder: Lift Cylinder, Locating Pin and Hole Clamp
Saves space required for lifting devices.
You can download application examples.
